to improve the wear life of high manganese wear parts

by inserting TiC rods? High manganese wearing part: hammer heads, jaw plates, blow bars,

impact plates, liner plates, mantle, concave, etc. Only 5% TiC

in the casting parts, and the working life is double increased!

I.Product technical parameters:
1.Hardness (ISO 3878): 82-89 HRA
2.Density :6.0-6.5g/cm3
3.TRS (ISO 3327): 1600±200 N/mm2
4.Average Grain Size: 1.0 +0.5 μm
5.Porosities: A02B00C00
6.CHEMICAL: TiC(47%)-Fe(37%)-Other(16%)

II.popular size:

D8   x  18/38
D10  x 40/50/60
D12 x 30/40/50/60/70/80
D12 x 65
D14 x 30/33/40/50/60/70/80
D16 x 30/40/50/60/70/80/90
D18 x 40/50/60/70
